11-10 Cable color coding
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Table 11-10
ESI DATA/CLK cable
Pin Color code Signal Pin
RJ-45 RJ-45
1 Brown UNUSED 1
2 Brown-Grey UNUSED 2
3 Red ESIDATA_BAL_RXP 3
4 Orange-Grey UNUSED 4
5 Orange UNUSED 5
6 Red-Grey ESIDATA_BAL_RXN 6
7 Yellow ESIDATA_BAL_TXP 7
8 Yellow-Grey ESIDATA_BAL_TXN 8
