Ciena 6200 - Page 239

Cable color coding 11-9
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Rx GROUP
RED
YELLOW
20 TIP-Rx17
GREEN 61 RING-Rx17
RED 19 TIP-Rx18
ORANGE 62 RING-Rx18
RED 18 TIP-Rx19
BLUE 63 RING-Rx19
WHITE 17 TIP-Rx20
GRAY 64 RING-Rx20
WHITE 16 TIP-Rx21
BROWN 65 RING-Rx21
WHITE 15 TIP-Rx22
GREEN 66 RING-Rx22
WHITE 14 TIP-Rx23
ORANGE 67 RING-Rx23
WHITE 13 TIP-Rx24
BLUE 68 RING-Rx24
RED
WHITE
12 TIP-Rx25
GREEN 69 RING-Rx25
RED 11 TIP-Rx26
ORANGE 70 RING-Rx26
RED 10 TIP-Rx27
BLUE 71 RING-Rx27
WHITE 9 TIP-Rx28
GRAY 72 RING-Rx28
WHITE 8 TIP-Rx29
BROWN 73 RING-Rx29
WHITE 7 TIP-Rx30
GREEN 74 RING-Rx30
WHITE 6 TIP-Rx31
ORANGE 75 RING-Rx31
WHITE 5 TIP-Rx32
BLUE 76 RING-Rx32
Table 11-9 (continued)
E1/DS1 LFH Cable
Group Cable Pins on the
Connector
Signal
Pair Color Bundle Color
