Cable color coding 11-3
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Table 11-4
Alarm in cable
Pin Color code Signal Pair
RJ-45
1 Blue GND P1
2 White ALARMIN_4
3Orange GND P2
4 White ALARMIN_3
5Green GND P3
6 White ALARMIN_2
7Brown GND P4
8 White ALARMIN_1
