6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Common procedures 10-
This chapter contains procedures for insertion and ejection of circuit pack and
other modules.
Note 1: Clean or replace air filter every six months or whenever required.
Note 2: Time between jack out and jack in of the card should be 30
seconds.
Note 3: PSU should not be removed with cables. Switch off the power
feed, unplug the cables, and then remove the PSU from the chassis.
Note 4: Make sure all cables are provided with a slack of approximately
two feet length additionally after the cable router so that the air filter and
fan units can be removed from chassis by adjusting the cable slack
provided.
Chapter procedure list
Table 10-1 shows all the procedures in the chapter.
Table 10-1
Chapter procedure details
Action Details
Inserting the power supply unit-DC PSU/Fan+OAM/
Fan+OAMV2 module
Procedure 10-1
Ejecting the power supply unit-DC PSU/Fan+OAM/
Fan+OAMV2 module
Procedure 10-2
Inserting and Ejecting the power supply unit-APU290 Procedure 10-3
Inserting circuit packs Procedure 10-4
Ejecting circuit packs Procedure 10-5
Installing and removing pluggable modules Procedure 10-6
