10-10 Common procedures
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 10-4 (continued)
Inserting circuit packs
Action
Step Action
1 Slide in the circuit pack along the guide ways provided on the chassis with the
latches in the open position to engage them to the chassis groove.
2 Operate the two latches inwards simultaneously to engage the circuit pack to
the backplane.
Note: Software initialization can take up to five minutes and is complete
when the green LED turns on. If the red LED turns on, the circuit pack has
faults and must be returned to Ciena. For full details on LED indications, refer
to Table 4-1,Table 4-2, and Table 4-8 of Trouble Clearing and Module
Replacement Procedures, 009-6200-543.
3 Fasten the faceplate to the chassis using a manual Phillips screwdriver.
—end—
CAUTION
Risk of performance degradation
Failure to fasten the faceplate to the sub rack may
result in intermittent failures, because of poor
connectivity.
