4-6 Preparing for installation and commissioning
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Table 4-3
List of test equipment
Equipment
PDH generator and analyzer that supports1.5 Mbit/s, 2 Mbit/s, 34 Mbit/s and 45 Mbit/s data rate
SDH/SONET generator and analyzer that supports 155 Mbit/s, 622 Mbit/s, 2.5 Gbits/s and 10 Gbits/s
data rate
Ethernet frame generator and analyzer with RFC 2544 compliance
Digital multimeter
Optical power meter with LC-PC connector
PC (for Craft Access Terminal)
Cable assembly shielded RJ45-RJ45 crossover 5 meters
Cable assembly shielded RJ45-RJ45 straight 5 meters
Optical connector microscope kit
Optical cleaning kit
Optical patch cord, LC-PC, single mode, low loss, 1 m
Connector/cables for E1/DS1 tributary equipment
SMB to BNC cable
120 ohm E1/DS1 cable
75 ohms to 120 ohms impedance matching transformers
DDF cable
Connector/cables for 34/45 Mbit/s tributary equipment
SMB to BNC cable
Ethernet test cables
Cable assembly shielded RJ45-RJ45 straight/crossover 2 meters
Ethernet loopbacks (RJ45)
ESI/Alarms cables
USB- Open Clock Cable
Cable assembly shielded RJ45-open clock 5 meters
Cable assembly shielded RJ45-open alarm 3 meters
