Circontrol Post eVolve Smart Series - Phase II

SERVICE MANUAL –Post eVolve Smart
4 - DEVICE OVERVIEW
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 11
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
4.4.2 PHASE II
1 Hat
2 Door closure fasteners
3 CCL1-MINI
4 Locking system Plug A
5 Locking system Plug B
6 Thermostat LTK
7 Socket type 2 Plug A
8 Socket type 2 Plug B
9 Control power supply
10 Control MCB
11 Socket CEE 7/3 Plug A
12 Socket CEE 7/3 B
13 Mode 3 DIN rail
14 Control power supply
15 MCB CEE 7/3
16 Contactor CEE 7/3
17 Energy meters
18 Tamper
19 MCB plug protections
20 Contactor Socket
21 Input terminals
22 Heater
23 Surge protection
24 Input power supply
cables
25 Base
26 LCD
27 RFID reader
28 Door
29 RGB light state
indicator
30 Identification product
labels
31 Door closure
1
4
7
14
10
17
19
20
24
2
2
15
21
2
6
3
18
8
13
16
5
22
23
9
29
30
31
8
12
31
31
2
25
26
27
2
28
2
12
11
