SERVICE MANUAL –Post eVolve Smart
7 - CHARGE POINT SLAVE DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 26
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
7.2.3.2 CCL1-MINI WIRING CONNECTION
Following image shows a detailed schematic of the connections in the CCL1-MINI PCB.
Please, refer to “ TECHNICAL DATA” section for more details.
7.2.4 THREE-PHASE YTL METER – PHASE II
YTL meter is a three phase, four wire with RS-485, DIN rail, electronic meter. This meter
complies with EN50470-1/3 standards. It can measure the active and reactive energy
consumption.
