Circontrol Post eVolve Smart Series - 14.2 MODEL T; 14.3 MODEL S

SERVICE MANUAL –Post eVolve Smart
14 - TECHNICAL DATA
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 93
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
14.2 MODEL T
INPUT
Input voltage
400VAC Three-phase
Nominal input current
64A
Nominal input power
44kW
Input frequency
50/60Hz
OUTPUTS
PLUG A
PLUG B
Rated output current
32A
32A
Rated output
22kW
22kW
Output AC voltage
400VAC Three-phase
CHARGE SYSTEM
PLUG A
PLUG B
Mode 3 (IEC 61851)
Mode 3 (IEC 61851)
PROTECTIONS
PLUG A
PLUG B
MCB
Curve C
40A
40A
RCD
Type A
30mA
30mA
SOCKET OUTLETS
2 x Type 2 (UNE EN 62196-1) lock system
14.3 MODEL S
INPUT
Input voltage
230VAC Single-phase
Nominal input current
64A
Nominal input power
14,8kW
Input frequency
50/60Hz
OUTPUTS
PLUG A
PLUG B
Rated output current
32A
32A
Rated output
7,4kW
7,4kW
Output AC voltage
230VAC Single-phase
CHARGE SYSTEM
PLUG A
PLUG B
Mode 3 (IEC 61851)
Mode 3 (IEC 61851)
PROTECTIONS
PLUG A
PLUG B
MCB
Curve C
40A
40A
RCD
Type A
30mA
30mA
SOCKET OUTLETS
2 x Type 2 (UNE EN 62196-1) lock system
