SERVICE MANUAL –Post eVolve Smart
9 - OPTIONAL DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 63
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
9.7.1 WIRING CONNECTION
Following image shows a detailed schematic of the connections. Please, refer to “9.7.2”
section for the connection to the CCL1-MINI PCB or to “ TECHNICAL DATA” section for
more details.
A1
A2
A1
A2
K08.1
K08.2
Led indicator
Plug B
Led indicator
Plug A
+24Vdc
0Vdc 1
0Vdc 2
+24Vdc
0Vdc 1
0Vdc 2
PE
N Q03.01
F Q03.01
9.7.2 CCL1-MINI WIRING
Following image shows a detailed schematic of the connections in the CCL1-MINI PCB.
Please, refer to “ TECHNICAL DATA” section for more details.
K08.1
K08.2
