SERVICE MANUAL –Post eVolve Smart
8 - OTHER DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 39
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
8.2 LOW TEMPERATURE KIT (6 + 22)
The heater has two main elements:
1. Bimetal thermostats (6): It controls the temperature inside the Charge Point
enclosure to avoid the low temperature.
2. Heater (22): It is a self-regulating PTC element, that ensures a constant
temperature operation by preventing the formation of condensation.
8.2.1 TECHNICAL CHARACTERISTICS
8.2.1.1 THERMOSTAT
*The values above about heating power, current and temperature and obtained at 230Vac, 50Hz and
ambient temperature conditions of 20+ºC after working for 10 minutes.
