9.1.3.1 WIRING CONNECTION
Following image shows a detailed schematic of the connections. Please, refer to “
TECHNICAL DATA” section for more details.
9.2 PLUG SHUTTER (8,9)
The Charge Point plugs have electrical active parts which can be accessible for non-
qualified personnel that may involve an electrical risk for them. The plug shutter protects
people from these electrical active parts, avoiding any risk.
