14.4 MODEL SS
INPUT
Input voltage
230VAC Single-phase
Nominal input current
32A
Nominal input power
7,4kW
Input frequency
50/60Hz
OUTPUTS
PLUG A
PLUG B
PLUG A
Rated output current
16A
16A
Rated output
3,6kW
3,6kW
Output AC voltage
230VAC Single-phase
CHARGE SYSTEM
PLUG A
PLUG B
Mode 1 (IEC 61851)
Mode 1 (IEC 61851)
PROTECTIONS
PLUG A
PLUG B
MCB
Curve C
16A
16A
RCD
Type A
30mA
30mA
SOCKET OUTLETS
2 x CEE 7/3
14.5 MODEL TM
INPUT
Input voltage
400VAC Three-phase
Nominal input current
48A
Nominal input power
25.7kW
Input frequency
50/60Hz
OUTPUTS
PLUG A
PLUG B
Rated output current
32A
16A
Rated output
22kW
3.7kW
Output AC voltage
400VAC Three-phase
230VAC Single-phase
CHARGE SYSTEM
PLUG A
PLUG B
Mode 3 (IEC 61851)
Mode 1 (IEC 61851)
PROTECTIONS
PLUG A
PLUG B
MCB
Curve C
40A
40A
RCD
Type A
30mA
30mA
SOCKET OUTLETS
1 x Type 2 (UNE EN 62196-1) lock system & 1 x CEE 7/3
