SERVICE MANUAL –Post eVolve Smart
8 - OTHER DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 40
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
8.2.2 WIRING CONNECTION
Following image shows a detailed schematic of the connections. Please, refer to "
TECHNICAL DATA” section for more details.
THERMOSTAT
HEATER
MCB
Q03.1
8.2.3 DEVICE CONFIGURATION PROCEDURE
- Thermostat is installed at the top of the Charge Point. Please, refer to “
COMPONENTS OVERVIEW” section for more details.
- Heater is installed at the bottom of the Charge Point in order to supply heat
to all devices located in the upper part. Please, refer to “ COMPONENTS
OVERVIEW” section for more details.
The recommended setting of the thermostat is at 5ºC. If thermostat
value is changed, the normal operation of the devices can be
affected.
