Circontrol Post eVolve Smart Series - 14.8 MODEL C63-one

SERVICE MANUAL –Post eVolve Smart
14 - TECHNICAL DATA
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 96
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
14.8 MODEL C63-one
INPUT
Input voltage
400VAC Three-phase
Nominal input current
63A
Nominal input power
44kW
Input frequency
50/60Hz
OUTPUTS
PLUG A
Rated output current
63A
Rated output
44kW
Output AC voltage
400VAC Three-phase
CHARGE SYSTEM
PLUG A
Mode 3 (IEC 61851)
PROTECTIONS
PLUG A
MCB
Curve C
80A
RCD
Type A
30mA
SOCKET OUTLET
1 x Cable Type 2 (mandatory, UNE EN 62196-1)
