SERVICE MANUAL –Post eVolve Smart
1 - PREFACE
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 5
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
1 PREFACE
This manual provides service and maintenance information for Circontrol Charge Point,
which has been designed and tested to allow electric vehicle charging, specified in
IEC-61851.
This document has different sections describing electrical components inside the
Charge Point and a step-by-step installation procedure.
It is mandatory to follow the basic security information supplied in this manual to ensure
safe and proper installation.
Failure to follow safety instructions may involve personal injury, equipment damage and
danger of death. CIRCONTROL is not responsible for events arising from such breach.
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
SAFETY INSTRUCTIONS IN THIS DOCUMENT
Before performing any maintenance, repair or manipulation of any
equipment connections, disconnect the device from any power source.
Pay attention to the instructions before performing any action to avoid
any error, device failure or any detail that can be overlooked.
Do not modify the unit. If modified, Circontrol will reject all responsibility
and the warranty will be void.
All technical data contains all the necessary information to identify and make the
replacement of the damaged part and make the commissioning for proper operation.
Certification
• Complies with IEC 61851, Electric vehicle conductive charging system (IEC 61851-1 and
IEC 61851-22).
• Complies with IEC 62196, Plugs, socket-outlets, vehicle couplers and vehicle inlets (IEC
62196-1 and IEC 62196-2).
• Standards: 2014/35/UE, LVD;2014/30/UE, EMC.
• RFID complies with ISO 14443A/B.
• Modem 4G complies with CE/RED
