SERVICE MANUAL –Post eVolve Smart
7 - CHARGE POINT SLAVE DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 25
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
7.2.3 SINGLE-PHASE YTL METER – PHASE II
YTL meter is a single phase, two wire with RS-485 DIN rail electronic meter. This meter
complies with EN50470-1/3 standards. It can measure the active and reactive energy
consumption.
7.2.3.1 WIRING CONNECTION
Following image shows a detailed schematic of the connections in the CCL1-MINI PCB
and in each Plug. Please, refer to “7.2.3.2” section for more details.
