9 - OPTIONAL DEVICES
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941 65
Web: www.circontrol.com – E-mail: circontrol@circontrol.com
3
Place the isolation rubber as follows on the anti-vandal lock.
4
Place the anti-vandal lock and assemble it with the Tongue Groove Pliers.
5
Final position must be like in the picture below; otherwise it will not be possible to
release the key from the lock system when opening and closing the door.
6
Use the Screwdriver to assemble the whole mechanism.
7
Check piston position to know if system is locked or unlocked.
