4-20

Catalyst 6500 Series Switches Installation Guide

OL-5781-04

Chapter 4 Removal and Replacement Procedures

Removing and Installing the DC-Input Power Supplies

Figure 4-14 DC-Input Wire Connections on the Terminal Block (WS-CDC-2500W)

INPUT

FAN

OUTPUT

FAIL

85907

Power leads

attached to

terminal block

( - ) Negative

(+) Positive

( ) Ground

Captive

installation

screw

Power

switch

DC-input cable
