4-19
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 4 Removal and Replacement Procedures
Removing and Installing the DC-Input Power Supplies
Figure 4-12 DC-Input Power Supply Front Panel (WS-CDC-2500W)
Figure 4-13 DC-Input Wire Connections on the Terminal Block (WS-CDC-1300W)
INPUT
OK
FAN
OK
OUTPUT
FAIL
I
0
85906
Power
switch
DC power cable
terminal block
Terminal block
cover
Status LEDs
Captive installation
screw
INPUT
OK
FAN
OK
OUTPUT
FAIL
I
0
18736
Power leads attached
to terminal block
(+) Positive
( - ) Negative
( ) Ground
Captive
installation
screw
DC-input power supply
with the terminal block
cover removed
Power
switch
DC-input cable
