4-68
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 4 Removal and Replacement Procedures
Installing the Air Filter Assembly on a Catalyst 6509-NEB-A Switch (Optional)
Figure 4-59 Removing the Inner Filter Retainer
Step 4 Place the foam filter over the filter retainer. (See Figure 4-60.)
Step 5 Slide the retainer and filter into the cage assembly.
1 Filter cage assembly 2 Filter retainer
3 Thumb loops 4 Tabs
104898
1
2
3
4
