Appendix B Transceivers, Module Connectors, and Cable Specifications
Transceivers
DWDM
XENPAK
Transceivers
Refer to Table B-11 for
specific product numbers
• DWDM XENPAK transceivers are used as part of a DWDM
optical network to provide high-capacity bandwidth across an
optical fiber network.
• There are 32 fixed-wavelength XENPAK transceivers that
support the International Telecommunications Union (ITU)
100 GHz wavelength grid. (See Table B-11 for a list of the
wavelengths.)
• Refer to your release notes for a list of compatible modules and
the software release level necessary to support these DWDM
XENPAK transceivers.
• Figure B-10 shows the physical appearance of the DWDM
XENPAK transceiver.
R/O WDM
XENPAK
Transceiver
WDM-XENPAK-REC
• The R/O WDM XENPAK receiver (WDM-XENPAK-REC)
operates as a pluggable receiver on any unidirectional link in a
CWDM or DWDM transport network; there is no transmitter in
the XENPAK.
• The receiver can be used for all wavelengths supported by Cisco
DWDM XENPAK transceivers.
• The W/O WDM receiver has a single SC connector.
• Refer to your release notes for a list of compatible modules and
the software release level necessary to support these R/O WDM
XENPAK receivers.
Table B-8 CWDM GBIC Transceivers
Model Number Color Code CWDM GBIC Wavelength
CWDM-GBIC-1470= Gray 1470 nm laser single-mode
CWDM-GBIC-1490= Violet 1490 nm laser single-mode
CWDM-GBIC-1510= Blue 1510 nm laser single-mode
CWDM-GBIC-1530= Green 1530 nm laser single-mode
CWDM-GBIC-1550= Yellow 1550 nm laser single-mode
CWDM-GBIC-1570= Orange 1570 nm laser single-mode
CWDM-GBIC-1590= Red 1590 nm laser single-mode
CWDM-GBIC-1610= Brown 1610 nm laser single-mode
