D-4
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
For all WS-X67xx modules, the values shown in Table D-4 are for the baseboard only. When the
baseboard has a CFC or DFC3 daughter card installed, you must add the daughter card power to the
baseboard power to get the total slot power. For all other modules that support a mandatory or optional
daughter card, you must add the daughter card power to the baseboard power to get the total slot power.
WS-SUP720-3BXL
Supervisor Engine 720 with
PFC3BXL daughter card and
integrated MSFC3 and switch
fabric
7.82 328.44 410.55 1402.03 441.45 1507.56
WS-F6K-PFC3A
Policy Feature Card 3A
2.25 94.50 118.13 403.40 127.02 433.76
WS-F6K-PFC3B
Policy Feature Card 3B
2.25 94.50 118.13 403.40 127.02 433.76
WS-F6K-PFC3BXL
Policy Feature Card 3BXL
2.57 107.94 134.93 460.77 145.08 495.45
Table D-3 Power Requirements and Heat Dissipation—Supervisor Engines (continued)
Table D-4 Power Requirements and Heat Dissipation—Modules
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-F6K-DFC
Distributed Forwarding Card
2.10 88.20 110.25 376.50 118.55 404.84
WS-F6K-DFC3A
Distributed Forwarding Card 3A
2.57 107.94 134.93 460.77 145.08 495.45
WS-F6K-DFC3B
Distributed Forwarding Card 3B
1.67 70.14 87.68 299.41 94.27 321.95
WS-F6K-DFC3BXL
Distributed Forwarding
Card 3BXL
2.38 99.96 124.95 426.70 134.35 458.82
WS-F6700-CFC
Centralized Forwarding Card
0.75 31.5 39.38 134.47 42.34 144.59
WS-F6700-DFC3A
Distributed Forwarding Card 3A
3.0 126 157.5 537.86 169.35 578.35
WS-F6700-DFC3B
Distributed Forwarding Card 3B
2.7 113.40 141.75 484.08 152.42 520.51
WS-F6700-DFC3BXL
Distributed Forwarding
Card 3BXL
3.3 138.60 173.25 591.65 186.29 636.18
