D-5
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-F6700-DFC3C
Distributed Forwarding Card 3C
for use on CEF720 modules.
Supported only with Supervisor
Engine 720 and
WS-X6708-10GE.
1.65 69.30 86.63 295.82 93.15 318.09
WS-F6700-DFC3CXL
Distributed Forwarding
Card 3CXL for use on CEF720
modules. Supported only with
Supervisor Engine 720 and
WS-X6708-10GE.
2.35 98.70 123.38 421.33 132.66 453.04
WS-C6500-SFM
Switch Fabric Module
2.79 117.18 146.5 500.2 157.5 537.86
WS-X6500-SFM2
Switch Fabric Module 2
3.09 129.78 162.23 554 174.4 595.7
WS-X6024-10FL-MT
24-port 10BASE-FL Ethernet
module
1.52 63.84 79.8 272.52 85.81 293.0
WS-X6066-SLB-APC
Content Switching Module
3.0 126.0 157.5 537.9 169.35 578.35
WS-X6101-OC12-SMF
WS-X6101-OC12-MMF 1-port
ATM module
2.10 88.2 110.3 376.5 118.5 404.8
WS-X6148-FE-SFP
48-port 100BASE-X module
2.3 96.60 120.75 412.36 129.84 443.40
WS-X6148-GE-TX
48-port 10/100/1000 Ethernet
module
2.47 104.0 130.0 443.0 139.0 476.0
WS-X6148V-GE-TX
48-port 10/100/1000 Ethernet
module with
WS-F6K-VPWR-GE PoE
daughter card
2.89 121.38 151.72 518.14 163.15 557.14
WS-X6148-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
2.65 111.30 139.13 475.11 149.60 510.87
WS-X6148A-GE-TX
48-port 10/100/1000 Ethernet
module
2.5 105.0 131.25 448.22 141.13 481.96
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
