Cisco 6509 - Catalyst Chassis Switch User Manual

D-6
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-X6148A-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
2.68 112.56 140.70 480.49 151.29 516.66
WS-X6148-RJ-45
48-port 10/100 Ethernet module
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6148A-RJ-45
48-port 10/100 Ethernet module
1.00 42.0 52.5 179.29 56.45 192.78
WS-X6148A-45AF
48-port 10/100 Ethernet module
2.57 107.94 134.93 460.77 145.08 495.45
WS-X6148-RJ-21
48-port 10/100 Ethernet module
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6148-RJ21V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.57 107.94 134.93 460.77 145.08 495.45
WS-X6148-RJ45V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.57 107.94 134.93 460.77 145.08 495.45
WS-X6148-21AF
48-port 10/100 Ethernet module
with WS-F6K-FE48-AF PoE
daughter card
2.57 107.94 134.93 460.77 145.08 495.45
WS-X6148-45AF
48-port 10/100 Ethernet module
with WS-F6K-FE48-AF PoE
daughter card
2.57 107.94 134.93 460.77 145.08 495.45
WS-X6148X2-RJ-45
96-port 10/100 Ethernet module
2.65 111.30 139.13 475.11 149.60 510.87
WS-X6148X2-45AF
96-port 10/100 Ethernet module
with WS-F6K-FE48X2-AF PoE
daughter card
2.65 111.30 139.13 475.11 149.60 510.87
WS-X6182-2PA
FlexWAN module
2.38 99.96 125 426.7 134.35 458.82
WS-X6196-RJ-21
96-port 10/100 Ethernet module
2.74 115.08 143.85 491.25 154.68 528.22
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
