D-7
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-X6196-21AF
96-port 10/100 Ethernet module
with WS-F6K-FE48X2-AF PoE
daughter card
3.16 132.72 165.90 566.55 178.39 609.19
WS-X6224-100FX-MT
24-port 100BASE-FX Ethernet
module, MMF
1.90 79.8 99.75 340.65 107.26 366.3
WS-X6248A-TEL
48-port 10/100 Ethernet module
(telco)
2.69 113 141.23 482.28 151.85 518.58
WS-X6302-MSM
Multilayer Switch Module
5.20 218.4 273 932.3 293.55 1002.47
WS-X6316-GE-TX
16-port 1000BASE-T Gigabit
Ethernet module
5.15 216.3 270.38 923.33 290.73 992.83
WS-X6324-100FX-MM
24-port 100BASE-FX Ethernet
module, MMF
1.52 63.84 79.8 272.52 85.81 293.03
WS-X6324-100FX-SM
24-port 100BASE-FX Ethernet
module, SMF
1.52 63.84 79.8 272.52 85.81 293.03
WS-X6348-RJ21V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6348-RJ-45
48-port 10/100 Ethernet module
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6348-RJ-45V
48-port 10/100 Ethernet module
with WS-F6K-VPWR PoE
daughter card
2.39 100.38 125.48 428.5 134.92 460.75
WS-X6380-NAM
Network Analysis Module
1.31 55.02 68.78 234.87 73.95 252.54
WS-X6408A-GBIC
8-port 1000BASE-X Gigabit
Ethernet module
2.00 84.00 105.00 358.58 112.90 385.56
WS-X6416-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
2.81 118.02 147.53 503.8 158.63 541.72
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
