D-8
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-X6416-GE-MT
8-port 1000BASE-SX Gigabit
Ethernet module
2.50 105.00 131.25 448.22 141.13 481.96
WS-X6502-10GE
2-port 10-Gigabit Ethernet
module
3.30 138.60 173.25 591.65 186.29 636.18
WS-X6516-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
3.40 142.80 178.50 609.58 191.94 655.46
WS-X6516A-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
3.62 152.04 190.05 649.02 204.35 697.87
WS-X6516-GE-TX
16-port 10/100/1000 Ethernet
module
3.45 144.90 181.13 618.54 194.76 665.10
WS-X6524-100FX-MM
24-port 100BASE-FX Ethernet
module
1.90 79.8 99.75 340.65 107.3 366.3
WS-X6548-GE-TX
48-port 10/100/1000 Ethernet
module
2.98 125.16 156.45 534.28 168.23 574.49
WS-X6548V-GE-TX
10/100/1000 Ethernet module
with WS-F6K-VPWR-GE PoE
daughter card
3.40 142.80 178.50 609.58 191.94 655.46
WS-X6548-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
3.16 132.72 165.90 566.55 178.39 609.19
WS-X6548-RJ-21
48-port 10/100 Ethernet module
2.90 121.80 152.25 519.93 163.71 559.07
WS-X6548-RJ-45
48-port 10/100 Ethernet module
2.90 121.80 152.25 519.93 163.71 559.07
WS-X6582-2PA
Enhance FlexWAN module
2.50 105.00 131.25 448.22 141.13 481.96
WS-X6608-T1/E1
8-Port T1/E1 PSTN interface
module
1.98 83.16 103.95 355 111.77 381.71
WS-X6624-FXS
24-Port FXS analog interface
module
1.54 64.68 80.85 267.10 86.94 296.88
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
