D-9
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-X6704-10GE
4-Port 10-Gigabit Ethernet
module
6.28 263.76 329.70 1125.93 354.52 1210.67
WS-X6708-10G-3C
8-Port 10-Gigabit Ethernet
module
10.58 444.36 555.45 1896.86 600.49 2050.66
WS-X6708-10G-3CXL
8-Port 10-Gigabit Ethernet
module
11.28 473.76 592.20 2022.36 640.22 2186.34
WS-X6724-SFP
24-Port 1000BASE-X Ethernet
module
2.23 99.66 117.08 399.81 125.89 429.90
WS-X6748-SFP
48-Port 1000BASE-X Ethernet
module
5.32 223.44 279.30 953.81 300.32 1025.60
WS-X6748-GE-TX
10/100/1000 Ethernet module
7.00 294.00 367.50 1255.01 395.16 1349.48
WS-X6816-GBIC
16-Port1000BASE-X Gigabit
Ethernet module
3.84 161.28 201.60 688.46 216.77 740.28
WS-SVC-FWM-1-K9
Firewall Services Module
4.09 171.78 214.73 733.29 230.89 788.48
WS-SVC-IPSEC-1
IPSec VPN Services Module
1.89 79.38 99.23 338.85 106.69 364.36
WS-SVC-NAM-1
Network Analysis Module 1
2.89 121.38 151.73 518.14 163.15 557.14
WS-SVC-NAM-2
Network Analysis Module 2
3.47 145.74 182.18 622.13 195.89 668.95
WS-SVC-WLAN-1-K9
Wireless LAN Services module
3.10 130.20 162.75 555.79 175.0 597.63
WS-SVC-CSG-1
Content Services Gateway
module
3.00 126.0 157.5 537.86 169.35 578.35
WS-SVC-PSD-1
Persistent Storage Device
module
4.00 168.0 210.0 717.15 225.81 771.13
WS-SVC-MWAM-1
Multiprocessor WAN
Application module
3.57 149.94 187.43 640.06 201.53 688.23
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
