D-10
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix D Chassis and Module Power and Heat Values
WS-SVC-CMM
Communications Media module
6.00 252.0 315.0 1075.73 338.71 1156.69
ACE10-6500-K9
Applications Control Engine
(ACE) module
5.23 219.66 274.58 937.67 295.24 1008.25
WS-SVC-WISM-1-K9
Wireless Services Module
(WiSM)
6.07 254.94 318.68 1088.25 342.66 1170.19
WS-SVC-AON-1-K9
Application-Oriented
Networking (AON) Module
4.00 168.00 210.00 717.15 225.81 771.31
WS-SVC-WEBVPN-K9
WebVPN Services Module
2.94 123.48 154.35 527.11 165.97 566.78
WS-SVC-AGM-1-K9
Anomaly Guard Module
4.00 168.00 210.00 717.15 225.81 771.13
WS-SVC-ADM-1-K9
Traffic Anomaly Detector
Module
4.00 168.00 210.00 717.15 225.81 771.13
WS-X6066-SLB-S-K9
Content Switching Module with
SSL
2.15 90.30 112.88 385.47 121.37 414.48
WS-SVC-IDSM2-K9
Intrusion Detection System
Module 2
2.50 105.00 131.25 448.22 141.13 481.96
Table D-4 Power Requirements and Heat Dissipation—Modules (continued)
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
