1-14
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6504-E Switch
Fan Tray • Supports one hot-swappable fan tray. These fan tray models are
supported:
– FAN-MOD-4HS—300 CFM
Note The fan tray contains eight individual fans. The individual fans
are not field replaceable. You must replace the fan tray.
• Fan tray STATUS LED
– Red—One or more individual fans have failed.
– Green—Fan tray is operating normally.
Power Supplies
• Supports one or two power supplies. The following power supplies are
supported:
– PWR-2700-AC/4 (2700 W AC-input power supply).
– PWR-2700-DC/4 (2700 W DC-input power supply).
• Installed power supplies can be both AC-input, both DC-input, or one
AC-input and one DC-input. Power supplies can be configured in either
redundant or non-redundant mode.
• All Catalyst 6500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
• Single power supplies are installed in the lower power supply bay. The
second power supply is installed in the upper power supply bay.
Table 1-6 Catalyst 6504-E Switch Specifications
Item Specification
Environmental
Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C)
Designed and tested for operation: 32° to 130°F (0° to 55°C)
Note The Catalyst 6500 series switches are equipped with internal air
temperature sensors that are triggered at 40°C (104°F) generating a
minor alarm and at 55°C (131°F) generating a major alarm.
Temperature, nonoperating
and storage
–4° to 149°F (–20° to 65°C)
Thermal transition 0.5°C per minute (hot to cold)
0.33°C per minute (cold to hot)
Table 1-5 Catalyst 6504-E Switch Features (continued)
Feature Description
