1-15
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6504-E Switch
Humidity (RH), ambient
(noncondensing) operating
5% to 90%
Humidity (RH), ambient
(noncondensing)
nonoperating and storage
5% to 95%
Altitude, operating Certified for operation: 0 to 6500 feet (0 to 2000 m)
Designed and tested for: –200 to 10,000 feet (–60 to 3000 m)
Shock and vibration
This switch complies with Network Equipment Building Systems (NEBS)
(Zone 4 per GR-63-Core) in the following areas:
• Earthquake environment and criteria
• Office vibration and criteria
• Transportation vibration and criteria
Shock
•
Operational—5 G 30 ms, half-sine (IEC 68-2-27)
• Non-operational—20 G, 7.5 ms, trapezoidal
Vibration
Operational—3 Hz to 500 Hz,
Power Spectral Density (PSD)-0.0005 G
2
/Hz at 10 Hz and 200 Hz.
5 dB/octave roll off at each end. 0.5 hours per axis (1.12 Grms).
Acoustic Noise
64 to 76 dB. International Organization for Standardization (ISO) 7779:
Bystander position operating to an ambient temperature of 86°F (30°C).
Physical Characteristics
Dimensions (H x W x D) • 8.7 x 17.5 x 21.6 in. (22.09 x 44.45 x 54.86 cm).
• Chassis requires 5 RU
1
.
• The Catalyst 6504-E switch chassis is designed to install in standard
19-inch equipment racks that meet ANSI/EIA 310-D, IEC 60297, and
ETS 300-119 standards.
Weight
• Chassis only: 27 lb (12.25 kg).
• Chassis fully configured with 2 supervisor engines, 2 modules, and
2 AC-input power supplies: 97 lb (43.99 kg).
Table 1-6 Catalyst 6504-E Switch Specifications (continued)
Item Specification
