Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6509-NEB Switch
Power Supply • Supports one or two power supplies. The following models are
supported:
–
WS-CAC-2500W (2500 W AC-input power supply).
–
WS-CDC-2500W (2500 W DC-input power supply).
–
WS-CAC-3000W (3000 W AC-input power supply).
–
WS-CAC-4000W-US (4000 W AC-input power supply).
–
WS-CAC-4000W-INT (4000 W AC-input power supply).
–
PWR-4000-DC (4000 W DC-input power supply).
–
WS-CAC-6000W (6000 W AC-input power supply).
• Installed power supplies can be of different wattage ratings. Installed
power supplies can also be both AC-input, both DC-input, or one
AC-input and one DC-input. Power supplies can be configured in either
redundant or non-redundant mode.
• All Catalyst 6500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
• Single power supplies are installed in the left power supply bay. The
second power supply is installed in the right power supply bay.
1. Refer to the Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note for kit installation instructions.
Table 1-15 Catalyst 6509-NEB Switch Features (continued)
Feature Features
