Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 1 Product Overview
Catalyst 6513 Switch
Backplane Bandwidth • 32 GBps shared bus.
• 256 GBps switch fabric.
• 720 GBps switch fabric.
Clock and VTT Module
• Two replaceable clock modules (WS-C6513-CL=) provide clocking
signals to the EOBC channel and the switching bus.
• Three replaceable voltage termination (VTT) modules
(WS-C6K-VTT=) provide reference voltage for bus signals.
Fan Tray
• Supports one hot-swappable fan tray. These fan tray models are
supported:
–
WS-C6K-13SLOT-FAN (Standard fan tray—641 CFM). Supports
Supervisor Engine 2 only; does not support the Supervisor
Engine 32 or the Supervisor Engine 720.
–
WS-C6K-13SLT-FAN2 (Optional high-speed fan
tray—1090 CFM). Required for Supervisor Engine 32 and
Supervisor Engine 720. Supports Supervisor Engine 2.
Note You must install a high-speed fan tray when using a Supervisor
Engine 32 or a Supervisor Engine 720. You must install a
2500 W or higher capacity power supply in the chassis to power
the high-speed fan tray. The 2500 W power supply can be
powered from either 120 VAC or 220 VAC.
Note Both fan tray models contain 15 individual fans. The individual
fans are not field replaceable. You must replace the fan tray.
• Fan tray STATUS LED
–
Red—One or more individual fans have failed.
–
Green—Fan tray is operating normally.
Table 1-19 Catalyst 6513 Switch Features (continued)
Feature Description
