2-11
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 2 Preparing for Installation
Site Requirements
• Plan ahead. Your Catalyst 6500 series switches currently installed in an enclosed or partially
enclosed rack might meet ambient air temperature and air flow requirements now. However, if you
add more chassis to the rack or you add more modules to a chassis in the rack, the additional heat
generated might cause the ambient air temperature within the rack to exceed 40°C (104°F) and can
cause minor alarms.
If an individual fan within the assembly fails, the FAN STATUS LED turns red. Individual fans cannot
be replaced. To replace a fan assembly, see the “Removing and Installing the Fan Assembly” section on
page 4-57.
Refer to your software configuration guide for information on environmental monitoring.
Table 2-2 Catalyst 6500 Series Chassis Fan Tray Support
Chassis Supported Fan Trays Non-Supported Fan Trays
Catalyst 6503 FAN-MOD-3
FAN-MOD-3HS (high speed)
WS-C6503-E-FAN
Catalyst 6503-E WS-C6503-E-FAN FAN-MOD-3
FAN-MOD-3HS (high speed)
Catalyst 6504-E FAN-MOD-4HS (high speed) —
Catalyst 6506 WS-C6K-6SLOT-FAN
WS-C6K-6SLOT-FAN2 (high
speed)
WS-6506-E-FAN
Catalyst 6506-E WS-6506-E-FAN WS-C6K-6SLOT-FAN
WS-C6K-6SLOT-FAN2 (high
speed)
Catalyst 6509 WS-C6K-9SLOT-FAN
WS-C6K-9SLOT-FAN2 (high
speed)
WS-6509-E-FAN
Catalyst 6509-E WS-6509-E-FAN WS-C6K-9SLOT-FAN
WS-C6K-9SLOT-FAN2 (high
speed)
Catalyst 6509-NEB WS-C6509-NEB-FAN
WS-6509-NEB-UPGRD
1
(high
speed)
1. Optional high-speed fan tray is part of the WS-6509-NEB-UPGRD kit.
—
Catalyst 6509-NEB-A FAN-MOD-09 —
Catalyst 6513 WS-C6K-13SLOT-FAN
WS-C6K-13SLT-FAN2 (high
speed)
—
