show dsl interface atm
486
Cisco MWR 2941 Router Command Reference, Release 15.0(1)MR
OL-23890-01
Table 14 describes the significant fields shown in the display.
Table 14 show dsl interface atm Field Descriptions
Field Description
Modem Status Status of the modem. Possible states include the following:
DMTDSL_INVALID—Error state.
DMTDSL_STOP—Administrative down state.
DMTDSL_INIT—Restarting line.
DMTDSL_CHK_HW—Confirming that required HW exists.
DMTDSL_DLOAD_1—Downloading the init.bin file.
DMTDSL_DLOAD_2—Downloading operational firmware.
DMTDSL_MODE_CHK—Verifying that download was
successful.
DMTDSL_DO_OPEN—Issue ADSL_OPEN command.
DMTDSL_RE_OPEN—Cycle the link. Retry open.
DMTDSL_ACTIVATING—Waiting for activation to succeed.
DMTDSL_LOOPBACK—Activation done.
DMTDSL_SHOWTIME—Activation succeeded.
DSL Mode DSL operating mode.
ITU STD NUM ITU standard number for the operating mode.
Vendor ID Vendor identification code.
Vendor Specific Indicates if this router is specified for a vendor.
Vendor Country Code for the country where the vendor is located.
Capacity Used Percentage of the capacity that is being used.
Noise Margin Noise margin, in decibels.
Output Power Power output, in decibels.
Attenuation Attenuation of the signal, in decibels.
Defect Status Status of defects.
Last Fail Code Last failure code that was logged.
Selftest Result Results of the self-test.
Subfunction Code for the subfunction running.
Interrupts Code for interrupts used.
PHY Access Err Number of physical access errors.
Activations Number of activations of the router.
SW Version Software version number.
FW Version Firmware version number.
Speed The train speed for upstream and downstream. It shows both the
interleave and the fast mode.
Reed-Solomon EC Reed-Solomon error-correction statistics.
