Cisco MWR 2941 Router Command Reference, Release 15.0(1)MR
show l2protocol-tunnel
548
Cisco MWR 2941 Router Command Reference, Release 15.0(1)MR
OL-23890-01
Drop Threshold for Encapsulated Packets: 3000
Port Protocol Shutdown Drop Encapsulation Decapsulation Drop
Threshold Threshold Counter Counter Counter
------- -------- --------- --------- ------------- ------------- -------------
Fa3/38 cdp ---- 3000 5 0 0
stp ---- 3000 2653 0 0
--- ---- ---- ---- ----
Router#
This example shows how to display a summary of Layer 2-protocol tunnel ports:
Router# show l2protocol-tunnel summary
COS for Encapsulated Packets:5
Drop Threshold for Encapsulated Packets:0
Port Protocol Shutdown Drop Status
Threshold Threshold
(cdp/stp/vtp) (cdp/stp/vtp)
------- ----------- ---------------- ---------------- ----------
Fa9/1 --- stp --- ----/----/---- ----/----/---- down
Fa9/9 cdp stp vtp ----/----/---- ----/----/---- up
Fa9/47 --- --- --- ----/----/---- 1500/1500/1500 down(trunk)
Fa9/48 cdp stp vtp ----/----/---- ----/----/---- down(trunk)
Router>
This example shows how to display Layer 2-protocol tunnel information on interfaces for a specific
VLAN:
Router# show l2protocol-tunnel vlan 1
COS for Encapsulated Packets: 5
Drop Threshold for Encapsulated Packets: 0
Protocol Drop Counter
-------- -------------
cdp 0
lldp 0
stp 0
vtp 0
Port Protocol Thresholds Counters
Shutdown Drop Encap Decap Drop
------------------- -------- --------- --------- --------- --------- ---------
Router#
Related Commands Command Description
l2protocol-tunnel Enables the protocol tunneling on an interface and specifies the type of
protocol to be tunneled.
l2protocol-tunnel
drop-threshold
Specifies the maximum number of packets that can be processed for the
specified protocol on that interface before being dropped.
l2protocol-tunnel
shutdown-threshold
Specifies the maximum number of packets that can be processed for the
specified protocol on that interface in one second.
