4-2
Cisco ONS 15454 Reference Manual, R7.0.1
OL-9217-01
Chapter 4 Optical Cards
4.1 4.1 Optical Card Overview
• 4.20 Optical Card SFPs and XFPs, page 4-49
4.1 Optical Card Overview
Each card is marked with a symbol that corresponds to a slot (or slots) on the ONS 15454 shelf assembly.
The cards are then installed into slots displaying the same symbols. See the “1.17 Cards and Slots”
section on page 1-68 for a list of slots and symbols.
4.1.1 Card Summary
Table 4-1 lists the Cisco ONS 15454 optical cards.
Table 4-1 Optical Cards for the ONS 15454
Card Port Description For Additional Information...
OC3 IR 4 SH 1310
The OC3 IR 4 SH 1310 card provides four
intermediate- or short-range OC-3 ports and operates
at 1310 nm.
Note The OC3 IR 4 SH 1310 and OC3 IR 4/STM1
SH 1310 cards are functionally the same.
See the “4.2 OC3 IR
4/STM1 SH 1310 Card”
section on page 4-5.
OC3 IR 4/ STM1
SH 1310
The OC3 IR 4/STM1 SH 1310 card provides four
intermediate- or short-range OC-3 ports and operates
at 1310 nm.
See the “4.2 OC3 IR
4/STM1 SH 1310 Card”
section on page 4-5.
OC3 IR/ STM1 SH
1310-8
The OC3 IR/STM1 SH 1310-8 card provides eight
intermediate- or short-range OC-3 ports and operates
at 1310 nm.
See the “4.3 OC3 IR/STM1
SH 1310-8 Card” section on
page 4-7.
OC12 IR 1310
The OC12 IR 1310 card provides one intermediate- or
short-range OC-12 port and operates at 1310 nm.
Note The OC12 IR 1310 and OC12/STM4 SH 1310
cards are functionally the same.
See the “4.4 OC12
IR/STM4 SH 1310 Card”
section on page 4-9.
OC12 IR/STM4 SH
1310
The OC12 IR/STM4 SH 1310 card provides one
intermediate- or short-range OC-12 port and operates
at 1310 nm.
See the “4.4 OC12
IR/STM4 SH 1310 Card”
section on page 4-9.
OC12 LR 1310
The OC12 LR 1310 card provides one long-range
OC-12 port and operates at 1310 nm.
Note The OC12 LR 1310 and OC12 LR/STM4 LH
1310 cards are functionally the same.
See the “4.5 OC12
LR/STM4 LH 1310 Card”
section on page 4-11.
OC12 LR/STM4
LH 1310
The OC12 LR/STM4 LH 1310 card provides one
long-range OC-12 port and operates at 1310 nm.
See the “4.5 OC12
LR/STM4 LH 1310 Card”
section on page 4-11.
OC12 LR 1550
The OC12 LR 1550 card provides one long-range
OC-12 port and operates at 1550 nm.
Note The OC12 LR 1550 and OC12 LR/STM4 LH
1550 cards are functionally the same.
See the “4.6 OC12
LR/STM4 LH 1550 Card”
section on page 4-13.
