Chapter 15 Performance Monitoring
15.5 15.5.7 DS3XM-6 Card Performance Monitoring Parameters
15.5.7 DS3XM-6 Card Performance Monitoring Parameters
Figure 15-14 shows the signal types that support near-end and far-end PMs.
Figure 15-14 Monitored Signal Types for the DS3XM-6 Card
Note The XX in Figure 15-14 represents all PMs listed in Table 15-10 with the given prefix and/or suffix.
Figure 15-15 shows where the overhead bytes detected on the ASICs produce PM parameters for the
DS3XM-6 card.
ONS 15454
PTE
DS3XM OC-N
Fiber
Muxed
DS3 Signal
Muxed
DS3 Signal
DS1 Path (DS1 XX) PMs Near and Far End Supported
ONS 15454
DS3XMOC-N
VT Path (XX-V) PMs Near and Far End Supported
PTE
78979
DS3 Path (DS3 XX) PMs Near and Far End Supported
STS Path (STS XX-P) PMs Near and Far End Supported
