Appendix A Hardware Specifications
A.3 A.3 General Card Specifications
A.3 General Card Specifications
This section provides power specifications and temperature ranges for all ONS 15454 cards.
A.3.1 Power
Table A-2 provides power consumption information for the ONS 15454 cards.
15454E-GBIC-LX/LH GE, FC –9 to –3 –19 to –3
ONS-GX-2FC-MMI FC –9.5 to –5 –20.5/–15 max
ONS-GX-2FC-SML FC –9 to –3 –18 to –3
1. Based on any valid 8B/10B code pattern measured at, or extrapolated to, 10E-15 BER measured at center of eye
2. Minimum Stressed Sensitivity (10-12): -12.5(62.5um) and -13.5(50um) dBm
3. Minimum Stressed Sensitivity (10
–12
): -14.4 dBm
Table A-1 SFP, XFP, and GBIC Specifications (continued)
SFP/XFP Product ID Interface
Transmitter Output
Power Min/Max (dBm)
Receiver Input Power
Min/Max (dBm)
Table A-2 Individual Card Power Requirements
Card Type Card Name Watts Amperes BTU/Hr.
Control Cards
TCC2 19.20 0.4 66.8
TCC2P 27.00 0.56 92.2
XCVT 34.40 0.72 117.46
XC10G 48 1 163.68
XC-VXC-10G 67 1.4 228.62
AIC-I 4.8 0.1 15.3
AEP 3 (from +5 VDC
from AIC-I)
10.2
