Chapter 1 Shelf and Backplane Hardware
1.8 1.8 UBIC-V Cables
Table 1-16 UBIC-V DS-1 SCSI Connector Pin Out
Port SCSI Pin SCSI Pin Port
#1 1 26 #7
FGnd 2 27 FGnd
FGnd 3 28 FGnd
FGnd 4 29 FGnd
#2 5 30 #8
FGnd 6 31 FGnd
FGnd 7 32 FGnd
FGnd 8 33 FGnd
#3 9 34 #9
FGnd 10 35 FGnd
FGnd 11 36 FGnd
FGnd 12 37 FGnd
#4 13 38 #10
FGnd 14 39 FGnd
FGnd 15 40 FGnd
FGnd 16 41 FGnd
#5 17 42 #11
FGnd 18 43 FGnd
FGnd 19 44 FGnd
FGnd 20 45 FGnd
#6 21 46 #12
FGnd 22 47 FGnd
FGnd 23 48 FGnd
FGnd 24 49 FGnd
#13 25 50 #14
