Appendix C Network Element Defaults
C.2 C.2.3 Defaults by Card
C.2.3.2 DS1/E1-56 Card Default Settings
Table C-2 lists the DS1/E1-56 card default settings.
Table C-2 DS1/E1-56 Card Default Settings
Default Name Default Value Default Domain
DS1-E1-56.config.OperatingMode All DS1 All DS1, All E1
DS1-E1-56.config.PortToVtMappingMode GR253 Industry when OperatingMode All
E1; GR253, Industry when
OperatingMode All DS1
DS1-E1-56.config.RetimingEnabled FALSE TRUE, FALSE
DS1-E1-56.DS1-PORT.config.AdminSSMIn STU PRS, STU, ST2, TNC, ST3E, ST3,
SMC, ST4, DUS, RES
DS1-E1-56.DS1-PORT.config.AINSSoakTime 08:00
(hours:mins)
00:00, 00:15, 00:30 .. 48:00
DS1-E1-56.DS1-PORT.config.Ds1Mapping Asynchrono
us
Asynchronous when LineType
UNFRAMED, UNFRAMED;
Asynchronous, Byte Synchronous
when LineType ESF, D4, E1_MF,
E1_CRCMF, AUTO FRAME,
J_ESF
DS1-E1-56.DS1-PORT.config.FdlMode T1.403 T1.403 when LineType
UNFRAMED, AUTO FRAME;
T1.403, BFDL when LineType
ESF, D4, J_ESF
DS1-E1-56.DS1-PORT.config.LineCoding AMI B8ZS, AMI
DS1-E1-56.DS1-PORT.config.LineLength 0 - 131 ft 0 - 131 ft, 132 - 262 ft, 263 - 393 ft,
394 - 524 ft, 525 - 655 ft
DS1-E1-56.DS1-PORT.config.LineType AUTO
FRAME
ESF, D4, UNFRAMED, AUTO
FRAME, J_ESF
DS1-E1-56.DS1-PORT.config.RetimingEnabled FALSE TRUE, FALSE
DS1-E1-56.DS1-PORT.config.SDBER 1E-7 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
DS1-E1-56.DS1-PORT.config.SendDoNotUse FALSE TRUE, FALSE
DS1-E1-56.DS1-PORT.config.SFBER 1E-4 1E-3, 1E-4, 1E-5
DS1-E1-56.DS1-PORT.config.State OOS,DSBL
D
IS, OOS,DSBLD, OOS,MT,
IS,AINS
DS1-E1-56.DS1-PORT.config.SyncMsgIn FALSE FALSE when LineType D4,
E1_MF, E1_CRCMF,
UNFRAMED, AUTO FRAME;
FALSE, TRUE when LineType
ESF, J_ESF
DS1-E1-56.DS1-PORT.pmthresholds.ds1network.farend.15min.ESFE 65 (seconds) 0 - 900
DS1-E1-56.DS1-PORT.pmthresholds.ds1network.farend.15min.ESNE 65 (seconds) 0 - 900
DS1-E1-56.DS1-PORT.pmthresholds.ds1network.farend.15min.SESFE 10 (seconds) 0 - 900
