Appendix C Network Element Defaults
C.2 C.2.3 Defaults by Card
C.2.3.16 OC-48 Card Default Settings
Table C-16 lists the OC-48 (OC48 IR 1310, OC48 LR 1550, OC48 IR/STM16 SH AS 1310, OC48
LR/STM16 LH AS 1550, OC48 ELR/STM16 EH 100 GHz, and OC48 ELR 200 GHz) card default
settings.
OC12-4.pmthresholds.sts3c-9c.nearend.1day.PJCDIFF 5760 (count) 0 - 1382400000
OC12-4.pmthresholds.sts3c-9c.nearend.1day.PJCS-PDET 9600 (seconds) 0 - 86400
OC12-4.pmthresholds.sts3c-9c.nearend.1day.PJCS-PGEN 9600 (seconds) 0 - 86400
OC12-4.pmthresholds.sts3c-9c.nearend.1day.PPJC-PDET 5760 (count) 0 - 691200000
OC12-4.pmthresholds.sts3c-9c.nearend.1day.PPJC-PGEN 5760 (count) 0 - 691200000
OC12-4.pmthresholds.sts3c-9c.nearend.1day.SES 7 (seconds) 0 - 86400
OC12-4.pmthresholds.sts3c-9c.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-15 OC12-4 Card Default Settings (continued)
Default Name Default Value Default Domain
Table C-16 OC-48 Card Default Settings
Default Name Default Value Default Domain
OC48.config.line.AdminSSMIn STU PRS, STU, ST2, TNC, ST3E, ST3,
SMC, ST4, DUS, RES
OC48.config.line.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
OC48.config.line.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
OC48.config.line.AlsRecoveryPulseDuration 2.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when AlsMode
Disabled, Auto Restart, Manual
Restart; 80.0, 80.1, 80.2 .. 100.0 when
AlsMode Manual Restart for Test
OC48.config.line.AlsRecoveryPulseInterval 100 (seconds) 60 - 300
OC48.config.line.PJStsMon# 0 (STS #) 0 - 48
OC48.config.line.SDBER 1E-7 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
OC48.config.line.Send<FF>DoNotUse FALSE FALSE when SendDoNotUse TRUE;
FALSE, TRUE when SendDoNotUse
FALSE
OC48.config.line.SendDoNotUse FALSE FALSE, TRUE
OC48.config.line.SFBER 1E-4 1E-3, 1E-4, 1E-5
OC48.config.line.State IS,AINS IS, OOS,DSBLD, OOS,MT, IS,AINS
OC48.config.line.SyncMsgIn TRUE FALSE, TRUE
OC48.config.sts.IPPMEnabled FALSE TRUE, FALSE
OC48.pmthresholds.line.farend.15min.CV 21260 (B2 count) 0 - 2212200
OC48.pmthresholds.line.farend.15min.ES 87 (seconds) 0 - 900
OC48.pmthresholds.line.farend.15min.FC 10 (count) 0 - 72
