Cisco ONS 15454 - Page 573

A-17
Cisco ONS 15454 Reference Manual, R7.0.1
OL-9217-01
Appendix A Hardware Specifications
A.5 A.5.2 DS1-14 and DS1N-14 Card Specifications
– Line code: AMI, B8ZS
– Termination: Wire-wrap, AMP Champ
– Input impedance: 100 ohms
– Cable loss: Max 655 feet ABAM #22 AWG
– AIS: TR-TSY-000191 compliant
• Output
– Bit rate: 1.544 Mbps +/– 32 ppm
– Frame format: Off, SF (D4), ESF
– Line code: AMI, B8ZS
– Termination: Wire-wrap, AMP Champ
– Input impedance: 100 ohms
– Cable loss: Max 655 feet ABAM #22 AWG
– AIS: TR-TSY-000191 compliant
– Power level: 12.5 to 17.9 dBm centered at 772 KHz, –16.4 to –11.1 dBm centered at 1544 KHz
– Pulse shape: Telcordia GR-499-CORE Figure 9-5
– Pulse amplitude: 2.4 to 3.6 V peak
– Loopback modes: Terminal and facility
• Electrical interface: BNC or SMB connectors
• Surge protection: Telcordia GR-1089
• Operating temperature
– C-Temp (15454-DS1-14 and 15454-DS1N-14): 0 to 131 degrees Fahrenheit (0 to
+55 degrees Celsius)
– I-Temp (15454-DS1-14-T and 15454-DS1N-14-T): –40 to 149 degrees Fahrenheit (–40 to
+65 degrees Celsius)
Note The I-Temp symbol is displayed on the faceplate of an I-Temp compliant card. A card
without this symbol is C-Temp compliant.
• Operating humidity: 5 to 95 percent, noncondensing
• Power consumption: 12.60 W, 0.26 A, 43.02 BTU/hr
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.716 in. (18.2 mm)
– Depth: 9.000 in. (228.6 mm)
– Card weight: 1.8 lb (0.8 kg)
