The following node types require the following
equipment. The cards and patch panels should already
be installed before you begin this procedure.
Expanded terminal nodes:
• One 40-WSS-C or 40-WSS-CE card
• One 40-DMX-C or 40-DMX-CE card
Plus one 40-channel patch panel tray, preinstalled
with MPO cables (each MPO cable is terminated on
one end with one MPO connector and on the other
end with eight LC-type connectors)
Expanded hub or ROADM nodes:
• Two 40-WSS-C or 40-WSS-CE cards
• Two 40-DMX-C or 40-DMX-CE cards
Plus two 40-channel patch panel trays, preinstalled
with MPO cables (each MPO cable is terminated on
one end with one MPO connector and on the other
end with eight LC-type connectors)
Tools/Equipment
NTP-G34 Installing Fiber-Optic Cables on DWDM
Cards and DCUs, on page 27
DLP-G427 Rerouting Fiber-Optic Cables in the
40-Channel Patch Panel Tray, on page 43
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
For a ROADM node, two patch panels will be used, one for the Side A and one for Side B. The Side B
40-WSS-C/40-WSS-CE card will connect to the Side B patch panel. The Side A 40-WSS-C/40-WSS-CE will
connect to the Side A patch panel. The MPO cables in the patch panel are preinstalled and routed out of the
left side of the patch panel tray.
Note
Procedure
Step 1 Choose either the Side A or Side B side of the shelf to cable the 40-WSS-C/40-WSS-CE and
40-DMX-C/40-DMX-CE cards.
If you are cabling cards on Side B of the shelf, you must first perform the DLP-G427 Rerouting
Fiber-Optic Cables in the 40-Channel Patch Panel Tray, on page 43 to route the MPO cables out
of the right side of the patch panel tray, or route the cables through a fiber storage panel.
Note
