Cisco PowerVu D9858 User Manual

4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-85
Diagnostics Menu
Structure
To view the Diagnostics menus from the Main menu, press the RIGHT arrow key
five times and then the SELECT key.
For instructions on how to select and store settings, see About the Front Panel,
page 4-2.
The Diagnostics menu has the following structure:
Alarms/Warnings History Menu
Description: This menu displays the system event messages.
View History: Select this option to view the system event messages. Press SELECT
to view the messages using the UP/DOWN arrow keys.
Clear History Select this option to clear any existing history information.
Logs
Description: This menu allows you to view system log messages.
View Logs: Select this option to view the system log messages. Press SELECT to
view the messages using the UP/DOWN arrow keys.
Clear Logs: Select this option to clear any existing log history information.
Alarm Reset 2/2
Loss of Signal 09/26 11:21:21
i
Main:Diagnostics 1/2
Alarms/Warnings History Logs PSI
i
s
Main:Diagnostics 2/2
PowerOn Health Monitor
i
s
Alarms/Warnings
Main:Diagnostics:History
View History Clear History
i
s
Alarm Set 1/2
Loss of Signal 09/26 11:20:00
i
Main:Diagnostics:Logs
View Logs Clear Logs
i
s
Alarms Warnings Browse Clear All
0 0
i
Alarm Set Date/Time
Loss of Signal 09/26 11:21:21
i
s
Power On
Health Monitor
Cur Temp Max Temp Avg Temp
33 37 34
i
Fan RPM
3120
i
Reason For Last Reset
i
Tot Rst # Clrbl Rst # Clr Rst #
0 0 [Yes]
i
Total Hrs Hrs Since Powerup
x x
i
Power On Date Power On Time
12/22/2007 12:17
i
TxID Freq FEC Pol Symrate
9 3.51 7/8 H 45.0
i
TxID ONID Mod OrbPos
9 65534 QPSK 120.0
i
Type ID Ver PID 1/2
i
s
Id VC TxID PMT ECM
[21] 100 9 5100 ----
i
s
Status Sections 2/2
i
s
Frequency Plan
Channels
PSI Tables
Frequency Plan Channels Tables
i
s
Id Program Name
[21] max length?
i
s
Main:Diagnostics:PSI
