3-8 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Section D - Connecting the Input/Output Signals
Connecting the Video Outputs
Connector for the Video Outputs
The video output connectors are of the BNC type.
Video Connector
The following table shows the video connector.
To Connect the Composite Video Ouput
Do as follows to connect to the Composite Video Output:
1. Connect a video monitor to the CVSB 1 and CVSB2 connectors. The two outputs
are identical.
Use a 75-ohm double-braided coax cable.
Connector Interface type Connector type
SMPTE 292M BNC female
