Keypad Convention
Overview
Throughout this manual, there are references to parts of a
keypad on the front of the transcoder. This is the
Navigation/Selection keypad (see diagram at right), which
changes its function, depending on the current state of the
menu. For clarity, the following table shows which parts of
this integral interface are being referenced by which term.
Keypad Button Function
SELECT Runs the highlighted command or opens the highlighted menu.
LEFT arrow When moving through menus, highlights the menu item to the
left. When entering data, moves the cursor to the left. In some
menus, backspaces over the data entry.
UP arrow Highlights the menu item above.
RIGHT arrow When moving through menus, highlights the menu item to the
right. When entering data, moves the cursor to the right.
DOWN arrow Highlights the menu item below.
Key Function Keypad Button
LEFT arrow Press the key on the left side of the
Navigation/Selection Keypad.
RIGHT arrow Press the key on the right side of the
Navigation/Selection Keypad.
UP arrow Press the key on the top of the
Navigation/Selection Keypad.
DOWN arrow Press the key on the bottom of the
Navigation/Selection Keypad.
SELECT Press the key in the center of the
Navigation/Selection Keypad.
