4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 3-7
Section C - Connecting the Input/Output Signals
Connecting the RF Inputs
Do as follows to connect to the RF inputs:
1. Connect up to four LNB RF cables to the RF connectors labelled RF1 through
RF4 on the rear of the unit.
Use 75-ohm (braid/foil or braid/braid), low insertion loss coaxial cable.
Each input accepts an LNB signal input. RF2 to RF4 require an external LNB
power source.
Connecting the ASI Input
Do as follows to connect to the ASI input:
1. If desired, connect to the ASI IN port to an asynchronous serial interface for
uplink monitoring.
