4-50 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Setup Menu: Outputs: TS Out: ASI, Continued
User Rate
Description: This parameter controls the output rate. It is only used if Rate
Control is set to User. This setting is used when the signal source is
RF or ASI. Note that output data may be lost when the user-selected
bit rate is set to a value that is less than the actual signal bit rate.
This allows you to set the output bit rate to a value expected by
equipment connected to the ASI output.
Parameters: 0 to 213 Mbps.
Output Mode
Description: This selects the DPM output mode.
Parameters: No Output, Passthrough, Service Channels Only, MAP
Passthrough, MAP Svc Chans Only, Full DPM Control or
Transcoding.
These settings are described in the table below.
Output Mode Description
No Output No ASI or MPEGoIP output will be generated.
Passthrough The output will be identical to the input. The output
channel will not be modified.
PE/PID remapping options, PSI regeneration and User
Rate are not supported in this mode.
Service Channels
Only
Only service channels will be output.
MAP Passthrough The output will be identical to the input, except that it
will be generated using the DPM and PID mapping
settings.
MAP Svc Chans
Only
Only service channels will be output according to the
DPM and PID mapping settings.
Full DPM Control The output will be generated according to the DPM
settings on the DPM: ASI or MOIP1 menus. This is a
manual control setting.
Transcoding The output will be generated using the DPM default
settings, except that the DPM action (Act) will be set to
Xcode and the Descramble Mode will be set to
Descrambled.
