4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide A-11
Section C - Transport Stream Outputs
ASI Output
MPEGoIP Output
Item Specification
Number of outputs 1
Type of connector 75 Ω BNC
Output impedance 75 Ω according to EN 50083-9
Data amplitude 800 mV peak-peak ± 10% according to
EN 50083-9
Return loss > 17 dB, 27 to 270 MHz
Transport stream bit rate 1 to 120 Mbit/s ± 100 ppm
ASI bit rate 270 Mbit/s ± 100 ppm
Transport stream formats According to EN 50083-9.
188 bytes structure,
204 bytes without Reed Solomon,
Burst or packet format.
Item Specification
Number of outputs 1
Type of connector RJ-45, 10/100/1000BaseT
Output modes UDP RAW, RTP
IP Addressing Multicast
TS Streaming MPTS
TS Bit Rate 1 to 120 Mbits/s
